MFG-CV01 · original concept GLB
Conveyor changeover rig
Rehearse a bottle-format A-to-B changeover and reject an obsolete lookalike block.
ExploreManufacturing model library
Equipment & 3D models
Seven original Manufacturing training concepts. Orbit, select named parts, inspect illustrative motion and download the versioned GLBs.
216 named components
Choose the equipment.
MFG-PU01 · original concept GLB
Pump and coupling training skid
Inspect a stopped pump/coupling concept and preserve the distinction between observation and a measured condition.
Explore
MFG-PK01 · original concept GLB
Packaging change-part bench
Capture why a format hub, key and transfer guide belong to one reviewed setup.
Explore
MFG-RB01 · original concept GLB
Robot task development cell
Explain a bounded pick/place task, gripper relationship and human review before hardware qualification.
Explore
MFG-QC01 · original concept GLB
First-piece inspection bench
Separate a visual first-piece observation from a calibrated, source-defined acceptance decision.
Explore
MFG-PN01 · original concept GLB
Pneumatic fault-learning panel
Trace an unpressurised illustrative circuit and decide when source or pressure evidence is missing.
Explore
MFG-EL01 · original concept GLB
Control-cabinet revision trainer
Locate components in an unwired cabinet concept and compare the physical identifier with the source revision.
ExploreUse the sources honestly.
These GLBs were authored for equipment familiarisation. They are not OEM CAD, customer scans or native Mirror Direct outputs. The conveyor extends the established SVG rig; the other six are original schematic training scenes. Approved geometry, operating SOPs and native simulations remain separate acceptance work.
Read provenance and missing inputs
